Orphek Atlantik V4 Gen 2

What else Orphek Atlantik V4 G2 is offering?

• A LED light that is made of full body acrylic. Our light is not only solid and durable, but also beautiful to display.
• A LED light that has a length of 24.21” (615mm), a width of 9.37” (238mm) and a height of 2.11” (53.6mm) .
• A LED light that comes not with any driver, but with Mean Well driver (model HLG-240H-48A) – we give you what the market has best to offer!
• A LED light that comes with a customized plug for your region.
• A LED light that comes with a hanging kit with no extra costs.

FEATURES

PROGRAM/CONTROL/MONITORING (IoT) Connectivity & Monitoring

• Built- in Wireless Worldwide Remote and Local programming, control and monitoring
• Compatible with Wi-Fi/ 3G and 4G Internet connectivity
• Compatible with IOS (iPhone and iPad) and Android (Cell and tablet)
• Free apps available
• Ability to program multiple Atlantiks individually, in groups or in unison.
• Eight pre-installed programs/ unlimited custom programs and group programming.
• Large storage with capacity for additional programs.
• Sunrise / Sunset  Full dimming capacity in all channels, 0-100% with progressive dimming.
• Strong clouds / soft clouds
•  Demo Mode Color Change  (Jellyfish Mode)

CHECK WHAT COMES WITH YOUR LIGHT! (INCLUDED)

• Power cord with waterproof connector
• Stainless steel hanging kit
• Mean well Fan-less IP65 power supply

CHECK WHAT IS ALSO AVAILABLE TO PURCHASE! (NOT INCLUDED)

• 3m extension cable
• ORPHEK Router (You can use your own)
• ORPHEK Gateway2 – ability to control 200+ units.

WHAT ABOUT THE GATEWAY? IS IT NECESSARY TO PURCHASE IT?

YES! YOU NEED TO PURCHASE ORPHEK MASTER GATEWAY. With the Orphek Gateway2 you will be able to enjoy fast, out-of-the-box setup & the ability to control and program your lights from anywhere in the world where internet access is available.

Color/Materials

• Light Unit Body Material: Black acrylic housing and silver stainless steel grill

Lens Options:

• Default :Wide convex 120 degree

• Custom: For Deep Aquarium  90degree , 60degree , 45degree ,15degree, 5 degree

Weight

• Light Unit Weight: 16.7 lbs (7.6kg)
• Power box Weight:  2.2 lbs (1.02 kg)

Package Dimensions / Weight

• Length: 27.55″ (700 mm)
• Width: 17.71″ (450 mm)
• Height: 7″ (180 mm)
• Package Weight:25.35 lbs ( 11.5 kg )
• Package V.W.:26.45 lbs ( 12 kg )

Cords

• Power extension cord with waterproof connector from Light Unit to Power Box: total 112? (2.85m)
• Power Cord:  59″ (1.5 m)

Hanging Kit

• 2 steel cables:  9.84” (250 mm)
• 1 steel cable:  70.86” (1.8 m)

Dimensions

• Length: 24.21” (615mm)
• Width: 9.37” (238mm)
• Height: 2.11” (53.6mm)

Electrical

• Mean Well Driver Model: HLG-240H-48A
• Input voltage: 100 ~ 240 / VAC277 – VAC for North America only
• Frequency: 47 ~ 63Hz
• Power consumption:  201~235 watt
• PF (power Factor) 0.973
• Input Current (Amps) 0.883
• Input Voltage (V) 217
• Output Voltage(V)  48
• Electrical outlet:  Region appropriate
